100G ZR QSFP28 Digital Optics Transceiver

PRODUCT FEATURES

• F-tone Optics module, hot-pluggable QSFP28 form factor
• IEEE 100G Ethernet (CAUI-4) or ITU-T 100G OTN (OTL4.4) compliant host interface
• 100G optical F-toneinterface with DP-DQPSK modulation and Staircase FEC per IEEE Std. 802.3-2022 100GBASE-ZR or ITU-T G.709.2
• Transmission reach:
  o Up to 80km unamplified (loss limited)
  o Up to 120km amplified (dispersion limited,
  optionally extendable to 300km)
• Full C-band tunable, 50GHz or 100GHz grid with optional FlextuneTM automatic wavelength tuning
• Case temperature range 0°C to 70°C (C-temp) or -40°C to 85°C (I-temp)
• Power dissipation < 5.5W (C-temp) or < 6.0W(I-temp)
• Remote digital diagnostics monitoring

APPLICATIONS

• Access and aggregation networks
• Cable TV networks
• Wireless front-haul & mid-haul

Description
The F-tone FTQ2-HG-ZRX QSFP28 Optics (DCO) transceiver supports 100G transmission over distances up to 120km (dispersion limited, optionally extendable to 300km) for edge network applications. On the host side, the module can accommodate IEEE 100GE Ethernet or ITU-T OTN OTU4 signals. The line side F-tone interface specifications are aligned with IEEE Std. 802.3-2022 100GBASE-ZR [8] and ITU-T G.698.2 DW50U-8A2(C)F / DW100U-8A2(C)F [11], which define a 27.95GBd dual-polarization differential QPSK modulation format.
The module is offered in both commercial temperature (0°C to 70°C) and industrial temperature (-40°C to 85°C) versions, with power dissipation of less than 6.0W. The local oscillator laser is full C-band tunable and the transceiver can optionally be configured to support FlextuneTM automatic wavelength tuning.
The transceiver module is compliant to the Specification for QSFP+ 28 Gb/s 4X Pluggable Transceiver Solution (QSFP28) [1] and specifications referenced therein [2-7]. The transceiver is RoHS compliant and lead-free per Directive 2011/65/EU [19].

北亿纤通 | F-tone Networks

企业邮箱： sales@f-tone.com
企业手机：19081343401
企业电话：028-85255257
企业传真：028-85977702

注：本产品有全国产化型号可选
本产品为QSFP28系列光模块（118），仅展示部分参数，如有需要，请联系我们。

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
