Features:
● Up to 1.25Gb/s Data Links
● Hot-Pluggable
● 1310nm FP laser transmitter
● LC connector
● Up to 20 km on 9/125μm SMF
● Single +3.3V Power Supply
● Monitoring Interface Compliant with SFF-8472
● Low power dissipation <1.5W typically
● Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C / -20°C to 85°C / 0°C to 70°C Version available
● RoHS compliant and Lead Free
Applications:
● Metro/Access Networks
● 1.25 Gb/s 1000Base Ethernet
● 1×Fiber Channel
● Other Optical Link
Description:
F-tone’s FTCS-T1312-20Dxx Small Form Factor Pluggable (SFP) Transceiver is a high performance, cost effective module which has a LC optics interface, Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. With no receiver.
北亿纤通 | F-tone Networks
企业邮箱： sales@f-tone.com
企业手机：19081343401
企业电话：028-85255257
企业传真：028-85977702
注：本产品有全国产化型号可选
本产品仅展示部分参数（va），如有需要，请您联系我们。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.resentative.
光学性能测试
测试光纤收发模块的眼图情况、接收灵敏度、消光比、波长、发光、光接收、电流和电压，以确保信号质量、传输的稳定性和可靠性。
Traffic Testing
测试误码率和丢包率，使其符合相应标准，确保收发器的性能。
光学性能测试
测试光纤收发模块的眼图情况、接收灵敏度、消光比、波长、发光、光接收、电流和电压，以确保信号质量、传输的稳定性和可靠性。
端面测试
检查光纤收发模块的端面并保持清洁，以实现更稳定的数据传输、更好的性能和耐用性。
