1.25G 多模1550nm 550m SFP光模块

Product Features
● Uncooled Laser Diode with MQW Structure
● InGaAs PIN-TIA Photodiode Receiver
● MMF
● Multi Mode Transceiver SFP Footprint
● LC Or SC Optical Interface Are Optional
● Compliant With SFP MSA and SFF-8472
● Digital Diagnostic Monitoring Interface
● Single +3.3V Power Supply
● CML Differential Inputs and Outputs
● LVTTL Signal Detection Output
● Compliant With ITU-T G.957
● Compliant With RoHS and Lead Free
● Metal Enclosure for Lower EMI
● Operating Case Temperature:
       Standard: 0 to +70°C
       Extend: -20 to +85°C
       Industrial: -40 to +85°C

Product Applications
● Fast Ethernet
● ATM/SONET/SDH
● Switch/Router
● Other Optical Transmission Systems

Absolute Maximum Ratings

Parameter	Symbol		Min	Max	Unit
Storage Temperature	Tst		-40	+85	°C
Operating Temperature	TO	BYCS-M1312-02D	0	+70	°C
		BYCS-M1312-02DE	-20	+85	°C
		BYCS-M1312-02DI	-40	+85	°C
Input Voltage	–		GND	VCC	V
Power Supply Voltage	VCC-VEE		0	+3.6	V

Note: Stress in excess of maximum absolute ratings can cause permanent damage to the module.

Recommended Operating Conditions

Parameter	Symbol		Min	Typ	Max	Unit
Storage Temperature	Tst		-40	–	+85	°C
Operating Case Temperature	TC	BYCS-M1312-02D	0	–	+70	°C
		BYCS-M1312-02DE	-20	–	+85	°C
		BYCS-M1312-02DI	-40	–	+85	°C
Power Supply Voltage	VCC		3.1	3.3	3.5	V
Power Supply Current	ICC		–	–	300	mA
Data Rate	DR		–	1250	–	Mbps

Optical Specification

Transmitter
Parameter		Symbol	Min	Typ	Max	Unit	Note
Center Wavelength	1310 DFB	λC	1261	1310	1360	nm
Spectral Width		Δλ	–	–	1	nm	–
Average Optical Output Power		Po	-10	–	-3	dBm
Extinction Ratio		ER	9	–	–	dB	–
Optical Rise/Fall Time(20%-80%)		Tr/Tf	–	–	0.26	ns	–
Output Eye Diagram		Compliant with ITU-T G.957
Receiver
Parameter		Symbol	Min	Typ	Max	Unit	Note
Operate Wavelength		–	1100	1310	1600	nm	BYCS-M1312-02Dxx
Receiver Sensitivity		RSENS	–	–	-20	dBm	1
Receiver Saturation		PRS	0	–	–	dBm	1
LOS Assert		–	-36	–	–	dBm	Alarm: High-level
LOS De-Assert		–	–	–	-26	dBm
LOS Hysteresis		–	0.5	–	5	dBm	–

Note:1.MinimumSensitivity and saturation levels for a 2^7-1PRB Stest pattern@1250Mbps.

Electrical Specification

Transmitter
Parameter		Symbol	Min	Typ	Max	Unit	Note
Power Supply Current		ICCT	–	70	150	mA	2
Input Differential Impedance		ZIN	90	100	110	Ω	–
Input Swing Differential Voltage		VIN	500	–	2400	mV	3
TX-Disable Voltage	Disable	–	2.0	–	VCC	V	–
	Enable	–	0	–	0.8	V	–
TX-Fault Voltage	Fault	–	2.0	–	VCC	V	–
	Normal	–	0	–	0.8	V	–
Receiver
Parameter		Symbol	Min	Typ	Max	Unit	Note
Power Supply Current		ICCR	–	70	140	mA	2
Output Swing Differential Voltage		VOUT	600	–	2000	mV	4
LOS Voltage	High	–	2.0	–	VCC	V	–
	Low	–	0	–	0.8	V	–

Note:

2. The current excludes the output load current.
3. CML input, internally AC-coupled and terminated.
4. Internally AC-coupled.

Package Diagram
Board Layout Hole Pattern

LC Side Interface

Order Information

产品型号	封装	波长(-xx)	速率(xx)	传输距离  (-xx)	x	等级(x)
BYCS-M1312-02Dxx	SFP	M13=1310nmMMFM15=1550nmMMF	12=1.25G	02=550m  20=20km  40=40km	空 不带DDM  D 带DDM	空 商业级  E 扩展级  I 工业级
